1in M x F Water Hose Assembly
- 200 PSI working pressure
- Silicone-free tube and cover
- Lightweight, flexible, non-marking, and UV & Ozone resistant
Often used in custom applications, the ARTW Series is specially formulated from PVC compounds to provide excellent performance and outstanding value. It’s reinforced with a high tensile strength textile cord and design to perform like rubber. Common applications include general water service in industrial plants, irrigation supply lines and farm and ranch maintenance.
You can learn more about the product below. Contact our sales team to discuss your specific needs so we may partner with you for the perfect solution.
*For color replace "xx" with "BK" = black, "BL" = blue, "RD" = red, "YW" = yellow, "GR" = green
*For length replace "yy" with 25, 50 or 100
Tube Material | Specially Formulated PVC Compound |
---|---|
Reinforcement | Synthetic high tensile strength cord |
Cover Material | Specially Formulated, Rubberized, PVC Blend |
Standard Colors | Red, Green, Black |
Standard Size(s) | 1in |
Standard Length(s) | 50, 75, 100 ft coils |
Temperature Range | 15◦ F (1.7◦ C) to 150◦ F (65◦ C) |
Working Pressure | 200 psi |
Safety Factor | 3:1 |
Assembled | Yes |
Fittings Available | Hvy Dty Brass 1"-11 1/2 NPSH MxF |
Phthalate Free | No |
RoHS Compliant | Yes |
Compare To | Kuriyama Series A1307, Contitech Pilcord, Contitech Pathfinder, Kentak 165, Kentak CLW |
Weight per foot | 0.43 |
